The Champion Power Equipment 201049 4500-Watt Open Frame Inverter Generator with CO Shield is 1 of the most advanced products on the market. Champion’s recoil start features Cold Start Technology with a reliable 224cc Champion engine that produces 4500 starting watts, 3650 running watts and runs for 17-hours at 25% load when the 2.9 Gal. fuel tank is full. with a 0.6 qt. oil capacity (recommended 10W-30 and funnel included). Economy Mode monitors power consumption in real time to extend your run time. with Economy Mode on, the engine idles lower, providing quieter operation, extended engine life and higher fuel economy. The covered outlets in this RV Ready inverter include a120-Volt 30 Amp RV (TT-30R), two 120-Volt 20 Amp household outlets (5-20R) and a 12-Volt DC automotive-style outlet with a dual USB adapter. CO Shield technology monitors the accumulation of carbon monoxide (CO), a poisonous gas produced by engine exhaust when the generator is running. If CO Shield detects unsafe elevated levels of CO gas, it automatically shuts off the engine. CO Shield is not a substitute for an indoor carbon monoxide alarm or for safe operation. DO NOT allow engine exhaust fumes to enter a confined area through windows, doors, vents or other openings. Generators must ALWAYS be used outdoors, far away from occupied buildings with engine exhaust pointed away from people and buildings. Meets the requirements of ANSI/PGMA G300-2018.
- Need help with service or repair, Champion Power Equipment is available to help 24-hours a day, 7-days a week
- 50% quieter and 20% lighter than a traditional champion 4500-Watt generator, plus our economy mode feature saves fuel and extends engine life
- Intelligauge keeps track of voltage, hertz and run-time hours to monitor output and track maintenance intervals, plus an LED indicates CO shutoff or fault
- UL-recognized sensor in CO shield will alert and shut off the generator automatically before harmful levels of carbon monoxide can accumulate, keeping you safe
- EZ start dial simplifies startup, then enjoy a quiet 64 dBA when RVing or tailgating and run up to 17-hours with 4500 starting and 3650 running watts on gasoline
- Includes 3-year limited warranty with free lifetime technical support from dedicated experts
-
Specifications
Dimensions: H 19.4 in, W 18.3 in, L 20.9 inDimensions
Product Height (in.) 19.4 in Product Length (in.) 20.9 in Product Width (in.) 18.3 in Details
Application Campsite, Emergency Use, Job Site, Recreation, Tailgating Built-in inverter Yes CA (CARB) Compliant CARB Compliant CO Shutoff Capable Yes Color Family Yellow Engine Displacement (cc) 224 Engine Make OEM Branded Engine Features 3-Prong Plug, 4-Prong Plug, Auto Idle Control, Built-in Fuel Gauge, CO Shutoff, Fuel Gauge, Low Oil Shutdown, Twist-Lock Plug, USB Port Fuel Tank Capacity (gal.) 2.9 gal Fuel Technology Single Fuel Full load fuel consumption (gallons/hour) .68 Generator Voltage 120 Half-Load Run Time (Hours) 8.5 Horsepower (hp) 0 hp Included Adapter, Oil Funnel Number of Outlets 4 Operational Volume (dB) 64 Outlet Type 120V 20A, 120V 30A, 12V DC Power/Fuel Type Gasoline Product Weight (lb.) 75 lb Returnable 30-Day Running Wattage 3650 Start Type Recoil Start Starting Wattage 4500 Suggested Uses Battery Charger, Halogen Work Light, Mobile Devices, Power Tools, RV A/C Unit, Small Appliances, Small Electronics Warranty / Certifications
Additional Resources
From the Manufacturer
Certifications and Listings CARB Compliant, EPA Approved Manufacturer Warranty 3 Year Limited Feature Packed Power on the Go
The perfect grab and go companion for your next camping trip, weekend getaway, or powering a few home essentials.
Advanced Technology On the Go
The reliable 224cc Champion engine runs for 17 hours at 50% load when the 2.9-gallon fuel tank is full.
Power Almost Everything in an Outage
The next time there’s an outage, the power in your house stays on.
Quick Touch Panel
Access all your controls in one spot, including your covered outlets, intelligauge, and economy mode switch.
5-Mode Intelligauge
Displaying run time, total time, voltage, hertz and power output.
RV Ready Inverter
A quiet, lightweight addition to your RV and a cost-effective power solution.
Covered Outlets For Protection
Outlets include 120V 30A RV (TT-30R), two 120V 20A household outlets (5-20R) and a 12V DC automotive-style outlet with a dual USB adapter.
17 Hours
Enjoy 17 hours of run time on a full tank of gasoline.
64 dBA
From 23 ft. the noise level is about as loud as normal speech.
EZ Start Dial
Takes the confusion out of starting an engine with easy access to your controls.
Quiet Operation
We cut the noise level in half by integrating Quiet Technology digital inverter components.
Parallel Ready
The kit (sold separately) allows you to link two units to double your power.
CO Shield®
Features CO Shield® carbon monoxide auto shutoff system.
